PoE+ Output and USB-C Power in One Compact Adapter

Designed to simplify UniFi deployments, this integrated AC adapter powers compatible UniFi Cloud Gateways via USB-C while delivering PoE+ output to a connected device. The Ubiquiti UACC-PoE+-USBC 30W PoE+ Integrated AC Adapter is ideal for adding PoE capability, supporting UniFi 5G backup, and maintaining clean installation flexibility.

Highlights

Integrated Power and PoE+ Output

• Powers a UniFi Cloud Gateway through USB-C
• Delivers up to 30 W PoE+ to a connected device
• Combines AC power, USB-C output, and PoE+ output in one adapter

Designed for UniFi Gateway Deployments

• Ideal for adding PoE output to supported UniFi gateways
• Supports UniFi 5G backup deployment scenarios
• Includes Gigabit LAN port for network connectivity

Flexible Installation Options

• Supports wall mounting
• DIN rail and floating mount options available separately
• 150 cm cable with split USB-C and Ethernet ends for cleaner installation

Reliable Electrical Protection

• Supports surge protection in difference and common mode
• Clamping protection for data and power lines
• NDAA compliant with CE, FCC, IC, UL, UKCA, CCC, and RoHS certifications

Key Features

Ubiquiti UACC-PoE+-USBC 30W PoE+ Integrated AC Adapter

• Integrated AC adapter with USB-C power and PoE+ output
• Type-C output: 5 V at 5 A
• PoE+ output: 48 V at 0.65 A
• Rated input voltage: 100 to 240 V AC at 50/60 Hz
• Maximum input current: 1.5 A

Compatible UniFi Devices

• UCG-Ultra
• UCG-Max
• UXG-Lite
• UXG-Max
• UX
• UX7
• U5G-Max-Outdoor
• U5G-Max
• U5G

Compact Deployment Design

• Dimensions: 146 x 62 x 42 mm
• Weight: 358 g
• Cable length: 150 cm total, including 30 cm split USB-C and Ethernet ends
• Power cord length: 180 cm
• Designed for wall, DIN rail, or floating mount deployment

Network and PoE Connectivity

• Gigabit LAN port included
• Data In / PoE through RJ45 shielded socket
• 4-pair powering using pins 1, 2, 4, 5 positive and 3, 6, 7, 8 negative
• Designed to add PoE+ output for compatible UniFi deployment needs

Electrical Protection and Performance

• Clamping protection: 11 V data, 60 V power
• Maximum surge discharge: 1500 A power
• Peak pulse current: 36 A data
• Response time: less than 1 ns
• Efficiency: 82%
• Output ripple: 1% maximum
• Line regulation and load regulation: 5% or lower

Operating Environment and Compliance

• Operating temperature: 0 to 40°C
• Storage temperature: -30 to 70°C
• Operating humidity: 10 to 95 percent non-condensing
• NDAA compliant
• Certified with CE, FCC, IC, UL, UKCA, CCC, and RoHS

Summary / Conclusion

The Ubiquiti UACC-PoE+-USBC 30W PoE+ Integrated AC Adapter is a practical accessory for UniFi gateway deployments that need USB-C power and PoE+ output from one compact solution. With support for multiple UniFi gateways, Gigabit LAN connectivity, flexible mounting, surge protection, and up to 30 W PoE+ output, it helps simplify installations while supporting cleaner and more reliable network expansion.
